ABB C Curve Single Pole MCB S280 Series

ABB C Curve Single Pole MCB S280 Series


₹ 1,615.00

Quantity

Min Qty : 1



Delivery Availability
EMI Available.

On minimum purchase of ₹ 3000/-

PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments

Product Description

  • The miniature circuit breakers of the System pro M compact series S 200 provide state-of-

  • the-art safety and comfort. They stand out due to their high performance and the wide

  • range of accessories and approvals.

  • The additional electrical currents 80 A and 100 A complement the current portfolio of the

  • System pro M compact and offer maximum performance in a single module width.

  • Clear contact position indication in red/green (“real CPI”)

  • Rated frequency f is of 50/60 Hz

  • Unique, patented twin terminal with captive screws and an increased opening for cables

  • up to max. 50 mm2, finger-proof (IP20)

  • Busbar slot in the back for best visibility during installation

  • High performance in building installations and industrial applications up to 6 kA at Ue =

  • 400 V AC acc. to IEC/EN 60947-2 and IEC/EN 60898-1

  • Individual product identification code

  • Approved acc. to IEC/EN 60898-1 and IEC/EN 60947-2 for global use

  • S280M Miniature Circuit Breaker,

  • Rated insulation voltage Ui acc. to IEC/EN 60664-1 (VDE 0110-1) IS OF 440 V AC

  • All MCBs of the product range S200M comply with IEC/EN 60898-1 and IEC/EN 609 47-2, allowing the use for residential, commercial and industrial applications.

Product Specifications

Rated Current

Code

Product Id

80

S201-C80

2CDS251001R0804

100

S201-C100

2CDS251001R0824
