SKU # 1000061264
Baker Dial Snap Gauge(Without Dial Gauge) 50-75mm DS75

PAN INDIA DELIVERY

100% Genuine Products

100% Secured Payments
Product Description
-
Designed for quick GO/NOT-GO gauging of diameters of cylindrical parts either inprocess or post process
-
Measuring spindle and anvil spindle are manufactured out of graded steel
-
Spindles are hardened and ground including screw threads
-
Carbide ground and lapped tip of measuring faces ensures maximum wear resistance
-
For quick entry, chamfer provided on front edges
-
Constant measuring force, which is a result of an in-built spring, eliminates user error
-
Once the gauge is set to zero with a master, we can measure the size directly
-
For easy reading, the indicator can be rotated and locked
-
Best suited for inspection of Continuous / Batch production items
-
Setting is done with the help of Gauge Blocks / Cylindrical Setting Masters
-
Any standard Dial Indicator with ø8 h6 mm holding shank can be fitted easily
-
Also used with Electronic probe & digital dial gauge
Product Specification
Brand |
Baker |
Product Type |
Dial Snap Gauge(Without Dial Gauge) |
Part Number |
DS75 |
Measuring Range |
50-75 mm |
Warranty |
As Per Manufacturer Terms And Conditions |
Other Details
Dimension (CM) - L x B x H |
|
Unit of Measurement |
|
Weight |
kg |
Generic Type |
Dial Snap Gauges |
Manufacturer Details |
Baker Gauges Pvt Ltd, 33-1-2, Nagar Road, Pune-411014, India, Phone : 91-20-66093800 |
Packer Details |
Baker Gauges Pvt Ltd, 33-1-2, Nagar Road, Pune-411014, India, Phone : 91-20-66093800 |
Country of Origin |
India |
