SKU # 1000127689
GCE Unicontrols Single Stage Oxygen Regulator Brass Body
PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments
Product Description
-
Unicontrols are pressure regulators fully conforming to all paragraphs of International Standard ISO2503
-
The main focus during product design and manufacture was on providing excellent performance, robustness and durability and guaranteeing its uncompromised safety
-
The Unicontrol regulators use a filter protected fully encapsulated valve, well proven over several generations of GCE regulators
-
The body is made of solid forged, high quality brass, polished and chemically stabilized
-
The zinc die-cast bonnet is protected by a double layer powder painting to providing a guarantee corrosion resistance even in very aggressive environments
-
For operational safety the integrated Pressure Relief Valve, located on the rear of the body is designed to prevent end users from changing the factory setting
Product Specification
| Brand | GCE |
| Product Type | Oxygen Regulator |
| Body | Forged Brass, chemically stabilized (acid bright dipped) |
| Bonnet | Die-cast Zinc alloy, chemically stabilized and powder painted |
| Diaphragm | Diam. 55 mm fabric-reinforced EPDM rubber |
| Encapsulated Valve | Brass body sealed by PA or high-grade chloroprene rubber |
| Pressure Gauges | Non-bulkhead 63 mm gauges, class 2,5%, scale calibrated in Bar |
| Inlet Stem & Nut | Brass, geometry complying with BS-341 standard |
| Safety Valve | Non-adjustable, plastic housing |
| Control Elements | Ergonomic PA control knob, captive pressure adjusting screw |
| Warranty | As Per Manufacturer Terms and Condition |
