LAST SOLD AT ₹ 650.00

SKU # 1000030249

Havells C Curve MCB  Single Pole  40A-63A

Havells C Curve MCB Single Pole 40A-63A

₹ 650.00


Pack Qty : 1

Delivery Availability
EMI Available.

On minimum purchase of ₹ 3000/-

100% Genuine Products
100% Secured Payments

Product Description

  • Safety Terminals

  • To avoid improper cable termination, the safety terminals guide the cable towards the cage terminal for systematic termination

  • Bi Stable Clip

  • Every device is provided with a dual position DIN rail clip, so it becomes much easier to change a device from a device bank connected to a bus-bar, without disturbing the existing wiring

  • Large Cable Terminals

  • Suitable for copper and aluminum cables, these terminals are compatible with cables upto 35 mm 2 cross section area

  • Cooler Operation

  • Grooves provided on outer body, so that when individual poles are placed adjacent to each other in a distribution board it forms a very effective channel for better air circulation, resulting into a cooler operation

  • Precise hammer action

  • A hammer directly connectd to the plunger strikes the moving contact arm with a force proportional to the peak current there by forcibly separating the moving contact from the fixed contact much before the latch mechanism operates.this further reduces the opening time of the circuit breaker.

  • Low power consumption

  • Consumes less power, thus cost effective and energy saving.

  • 13 Plates Arc Chute for effective arc quenching

  • The arc extinguishing device comprises of 13 plates arc chute.the arc under the influence of the magnetic field and arc guide is moved into th arc chute where it is rapidly split and quenched.

Product Specification



Product Type

Miniature Circuit Breaker(MCB)

Product Code | Rated Current

DHMGCSPF040 | 40 A

DHMGCSPF050 | 50 A

DHMGCSPF063 | 63 A


C Curve

Execution (pole)

Single Pole


IS/IEC 60898-1


Suitable for protection against overload & short circuit for Lighting & other Domestic Loads


As Per Manufacturer Terms & Conditions

Other Details

Dimension (CM) - L x B x H

Unit of Measurement



Generic Type

C Curve 1 Pole MCB

Manufacturer Details

Havells India Ltd. Office: QRG Towers, 2D, Sector-126, Expressway, Noida-201304 (U.P), Phone : +91-120-3331000 Email:

Packer Details

Havells India Ltd. Office: QRG Towers, 2D, Sector-126, Expressway, Noida-201304 (U.P), Phone : +91-120-3331000 Email:

Country of Origin
