SKU # 1000010836
L&T [ Lauritz Knudsen ] Crono Digital Time Switch

PAN INDIA DELIVERY

100% Genuine Products

100% Secured Payments
Product Description
Supply Voltage |
110 – 240 VAC |
Supply Variation |
-20% to +10% |
Frequency |
50/60 Hz |
Power Consumption (Max.) |
6 VA |
Number of Programs |
25 ON/OFF programs |
Minimum Switching Time |
1 min |
Number of Operating Modes |
5 |
Description Modes |
AUTO - Program Run ON AUTO – Instant ON up to next Auto Event AUTO OFF – Instant OFF up to next Auto Event ON – Continuous ON OFF - Continuous OFF |
Display |
3 Lines Text LCD |
DST |
Programmable |
Clock accuracy |
+/- 2 s/day max. over the operating temp.range |
Power reserve from factory |
6 Years |
Contact Arrangement |
1 C/O |
Contact Rating |
16 A (NO) and 5 A (NC) @ 240 VAC / 24 VDC |
Utilization category: AC - 15 |
Rated Voltage (Ue): 120/240 V, Rated Current (le):3/1.5 A |
Utilization category: DC - 13 |
Rated Voltage (Ue): 24/250 V, Rated Current (le): 2.0/0.22/0.11 A |
Operating Temperature |
-10° C to +55° C |
Storage Temperature Range |
-10° C to +60° C |
LED Indication |
Red LED --> Relay ON |
Dimension (WxHxD) (in mm) |
36x90x65 |
Weight |
110 g |
Applications |
Ideal for lighting applications like street lighting, Advertising Displays, Glowsigns etc.. |
Product Specification
Cat. No |
Voltage Rating |
Contact Arrangement |
67DDT0 |
110 - 240 VAC |
1 C/O |
6GHDT0 |
24 VDC |
1 C/O |
69HDT0 |
12 VDC |
1 C/O |
Other Details
Dimension (CM) - L x B x H |
|
Unit of Measurement |
|
Weight |
kg |
Generic Type |
Digital Time Switch |
Manufacturer Details |
L&T Electrical & Automation 7th Floor, TC-II, Tower B, Prima Bay, Gate No.5, Saki Vihar Road, Powai, Mumbai-400072, Maharashtra, India |
Packer Details |
L&T Electrical & Automation 7th Floor, TC-II, Tower B, Prima Bay, Gate No.5, Saki Vihar Road, Powai, Mumbai-400072, Maharashtra, India |
Country of Origin |
India |
