Metravi Digital Cable & Fault Locator CFL-01

Metravi Digital Cable & Fault Locator CFL-01

Visit the Metravi Store

₹ 21,230.00

Quantity

Pack Qty : 1.0



Delivery Availability

 Estimated Dispatch Within 2 Days

Offers and Coupons
Coupon Image

Register to use Coupon Code C50 and get ₹50/- off on a purchase of ₹1000/- & above

EMI Icon

EMI Available On minimum purchase of ₹ 3000/-

PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments

Product Description

  • Finding conductors in walls, conductor interruptions, short circuit in conductors.

  • Conductor tracing in soil.

  • Detecting fuses assigning current circuits.

  • Tracing sockets and distribution sockets having accidently been covered by plastering.

  • Detecting interruptions and short circuits in floor heating.

  • Tracing metallic water and heating piping.

  • All application areas (both, voltage free and live) are performed without using any additional instrument.

  • Transmitter display indicates the transmission level, the transmission code, as well as the foreign voltage.

  • Receiver display indicates the reception level, the transmission code, as well as the mains voltage detection.

  • Automatic and manually adjustable sensitivity adjustment.

  • Acoustic reception signal may be switched off.

  • Auto Power Off.

  • Backlit display.

  • Additional lighting functions when working under bad lighting conditions.

  • Additional transmitters are available, as options, to extend or distinguish signals.

  • The built in fuses protect the instrument against overload or faulty manipulation.

Product Specification

Brand

Metravi

Product Code

CFL-01

Product Type

Digital Cable & Fault Locator

Voltage Range

12 to 400 V

Frequency Range (Hz)

0 to 60 Hz

Display

LCD

Power Supply

9V battery, NEDA1604, IE6F22

Output Signals

125 kHz

Fust

F0.5A 500V, 6.3 x32mm

Power Consumption

Max. 18mA

Temperature Range

-20 to 60 Degree C Max 80%RH (Non Condensing)

Weight

130 g


Other Details

Dimension (CM) - L x B x H

Unit of Measurement

Weight

kg

Generic Type

Digital Cable & Fault

Manufacturer Details

Metravi Instruments Pvt. Ltd. 31 Ganesh Chandra Avenue Elegance Building, 6th Floor Kolkata 700 013, West Bengal, India

Packer Details

Metravi Instruments Pvt. Ltd. 31 Ganesh Chandra Avenue Elegance Building, 6th Floor Kolkata 700 013, West Bengal, India

Country of Origin

India
