SKU # 1000138685
SKF Pillow Block Ball Bearing 20mm UCPA 204
PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments
Product Description
-
Short base pillow block ball bearing unit with extended inner ring and set screw locking, Japanese Industrial Standards
-
Short base pillow (plummer) block ball bearing units consist of an insert bearing mounted in a cast iron housing
-
This variant has threaded holes for attachment bolts and is suitable for applications where the direction of rotation is constant or alternating
-
It has an inner ring extended on both sides and is locked onto the shaft by tightening two set screws on the inner ring, making it easy to mount
-
The units are compliant with Japanese Industrial Standards (JIS)
-
Optimized for applications where space is limited
-
Ready to mount
-
Lubricated and sealed bearing
-
Quick locking onto the shaft
-
Extended inner ring for minimized shaft misalignment
-
Warranty and support will be provided by vendor
-
Note:*Actual product image may vary from that shown on the picture
Product Specification
| Brand | SKF |
| Product Type | Ball Bearing |
| Product Model | UCPA 204 |
| Shaft Diameter | 20 mm |
| pillow Block Centre Height | 30.2 mm |
| Housing Overall Width | 34 mm |
| Centre Distance Between Bolt Holes | 52 mm |
| Total Bearing Width | 31 mm |
| Basic Dynamic Load Rating | 12.7 kN |
| Basic Static Load Rating | 6.7 kN |
| Limiting Speed | 6 500 r/min |
| Housing Type | Pillow block |
| Number Of Bolt Holes For Fasteners | 2 |
| Fastening Bolt Hole Type | Threaded |
| Inner Ring Retaining Feature | Set screws |
| Bore Type | Cylindrical |
| Housing Material | Cast iron |
| Bearing Material | Bearing steel |
| Bearing Sealing | Seal and flinger on both sides |
| Lubricant | Grease |
| Note | Limiting speed with shaft tolerance h6 |
| Product Net Weight | 0.54 kg |
