Baker Digital Internal Micrometer 2-6mm SXTD1M-BT/SXTD1i-BT

Baker Digital Internal Micrometer 2-6mm SXTD1M-BT/SXTD1i-BT

₹ 244,820.00


Pack Qty : 1

Delivery Availability
100% Genuine Products
100% Secured Payments

Product Description

  • Bowers XTD digital internal micrometers give the operator the advantage of traditional quality ratchet gauges allied to advanced IP65 electronics

  • The extended mechanical travel of the XT range means that special heads can also be manufactured to accommodate users’ most awkward measuring problems

  • Measuring heads for threads, splines, slots, grooves, deep-holes and many more applications are available on request

  • The Bowers XT range of internal micrometers can be supplied as individual instruments or in complete sets

  • All XT instruments give the user the advantage of extended measuring travel with fixed anvils and UKAS certification of measuring head

  • IP65 Electronics

  • Simple 2-button operation

  • Large easy-to-read display

  • 3 preset memories

  • RS-232 output

  • Range 2 – 300 mm (0.080″ – 12″)

  • 2 – 6 mm: 2 point / 6 – 300 mm: 3 point measurement

  • Resolution 0.001 mm / 0.00005″

  • Tungsten carbide measuring faces on all 3-point heads from 12.5mm

  • Blind bore measurement from 2 mm – 6 mm and above 12.5 mm (0.500″)

  • Extensions available above 6 mm for deep hole measurement

  • Ratchet stop to ensure consistent measurement

  • Setting rings included with individual instruments and sets

  • UKAS certificates supplied as standard with all gauges

  • Serial number on all digital readouts and measuring heads

  • Heads with special anvils available to suit specific customer requirements e.g. threads, grooves, 2-point, spherical, splines etc

  • Internal Micrometers manufactured according to DIN 863, part 4

  • After sales service

Product Specification



Product Type

Digital Internal Micrometer

Part Number



0.001 mm/0.00005inch


2-6 mm/0.080inch-0.25inch


As Per Manufacturer Terms And Conditions
