SKU # 1000061856
Baker Digital Internal Micrometer 6-10mm SXTD3M-BT/SXTD3i-BT
PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments
Product Description
-
Bowers XTD digital internal micrometers give the operator the advantage of traditional quality ratchet gauges allied to advanced IP65 electronics
-
The extended mechanical travel of the XT range means that special heads can also be manufactured to accommodate users’ most awkward measuring problems
-
Measuring heads for threads, splines, slots, grooves, deep-holes and many more applications are available on request
-
The Bowers XT range of internal micrometers can be supplied as individual instruments or in complete sets
-
All XT instruments give the user the advantage of extended measuring travel with fixed anvils and UKAS certification of measuring head
-
IP65 Electronics
-
Simple 2-button operation
-
Large easy-to-read display
-
3 preset memories
-
RS-232 output
-
Range 2 – 300 mm (0.080″ – 12″)
-
2 – 6 mm: 2 point / 6 – 300 mm: 3 point measurement
-
Resolution 0.001 mm / 0.00005″
-
Tungsten carbide measuring faces on all 3-point heads from 12.5mm
-
Blind bore measurement from 2 mm – 6 mm and above 12.5 mm (0.500″)
-
Extensions available above 6 mm for deep hole measurement
-
Ratchet stop to ensure consistent measurement
-
Setting rings included with individual instruments and sets
-
UKAS certificates supplied as standard with all gauges
-
Serial number on all digital readouts and measuring heads
-
Heads with special anvils available to suit specific customer requirements e.g. threads, grooves, 2-point, spherical, splines etc
-
Internal Micrometers manufactured according to DIN 863, part 4
-
After sales service
Product Specification
|
Brand |
Baker |
|
Product Type |
Digital Internal Micrometer |
|
Part Number |
SXTD3M-BT/SXTD3i-BT |
|
Reading |
0.001 mm/0.00005inch |
|
Range |
6-10 mm/1/4inch-3/8inch |
|
Warranty |
As Per Manufacturer Terms And Conditions |
