GIC Liquid Level Controller 400VAC 4431AD1

GIC Liquid Level Controller 400VAC 4431AD1

Visit the GIC Store

₹ 1,720.00

Quantity

Pack Qty : 1



Delivery Availability

 Estimated Dispatch Within 2 Days

Offers and Coupons
Coupon Image

Register to use Coupon Code C50 and get ₹50/- off on a purchase of ₹1000/- & above

EMI Icon

EMI Available On minimum purchase of ₹ 3000/-

PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments

Product Description

  • Fully Automatic operation enabling both draining and filling simultaneously with a single device

  • Adjustable sensitivity level from 1k to 200k Ohm

  • Includes provision for Manual start

  • Protects submersible pumps against dry running and prevents overfilling

  • Enables maximum utilization of incoming liquid (eg. water) supply

  • Specially designed corrosion and shock resistant sensors to ensure trouble free operation

Product Specification

Brand

GIC

Product Type

Liquid Level Controller

Product Model

4431AD1

Supply Voltage

415VAC, +/-20%

Frequency

47Hz - 63Hz

Maximum Power Consumption

3VA

Device Characteristics

Conductive Sensor Probes

Stainless Steel SS304, 3 or 6 Nos

Sensor Length

10 cm

Control Action Modes

Only Draining, Only Filling, Draining & Filling Simultaneous (One Tank or Two tanks)

Sensitivity

1K to 200 K Ohm (Potentiometer adjustable)

Sensor Voltage & Current

12 Vp-p, 100 Hz,< 1 mA

Sensor Cable

Cable gauge (Min):0.5 sq mm Tin coated, Cable dia(Min):1.5mm
Max Cable Length-1000m (For set value < 50%)
Max Cable Length-300m (For set value 100%)
Max capacitances of wire- 80 nF / km

Settable On & Off Delay Time

0.5 sec to 10 sec

Manual Start Switch

If Lower tank water level is greater than Low level & upper tank water level is below High level then by
pressing a switch Relay can be switched ON manually

Output Control Mode

Relay ON/OFF

Contact Ratings

1 C/O,8A@250VAC,Resistive,Terminal 15-Pole, Terminal 16-NC,Terminal 18-NO

Utilization Category

AC-15: Rated Voltage (Ue):120/240V,
Rated Current(Ie): 3.0/1.5A
DC-13: Rated Voltage (Ue):24/125/250V,
Rated Current(Ie): 2.0/0.22/0.1A

Electrical Life

1 x 10 Operations

Mechanical Life

1 x 10 Operations

LED Indication

GREEN LED: Power ON,
RED LED : Relay Output ON

Operating Temperature

-10°C to +60°C

Storage Temperature

-10°C to +70°C

Relative Humidity

5 to 95 % RH (non condensing)

Mounting

Base/DIN Rail

Dimension (W x H x D)

36 x 90 x 65 mm

Weight (Unpacked)

235 g (Controller), 45 g (Sensor)

Warranty

As Per Manufacturer Terms and Condition

Other Details

Dimension (CM) - L x B x H

3.6 x 9 x 6.5

Unit of Measurement

1 Piece

Weight

0.5 kg

Generic Type

Liquid Level Controller

Manufacturer Details

Larsen & Toubro Limited L&T House, Ballard Estate, P. O. Box: 278, Mumbai 400 001 India

Packer Details

Larsen & Toubro Limited L&T House, Ballard Estate, P. O. Box: 278, Mumbai 400 001 India

Country of Origin

India
