Available

SKU # 1000012355

ABB XTMax MCCB 1.6-160 A 70 KA  415 V AC Three-Pole – XT2H 160 3p

ABB XTMax MCCB 1.6-160 A 70 KA 415 V AC Three-Pole – XT2H 160 3p


₹ 12,075.00

Quantity

Min Qty : 1



Delivery Availability
EMI Available.

On minimum purchase of ₹ 3000/-

PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments

Product Description

  • C.Breaker Tmax XT2H 160 Fixed Three-Pole With Front Terminals And Thermomagnetic Release TMA

  • Moulded-case circuit-breakers can be used in low voltage civil and industrial installations with 1 to 3200 A operating current.

  • Tmax circuit-breakers can be equipped with thermomagnetic,magnetic only or electronic trip units; all of which are interchangeable.

  • Product Net Width : 90 mm

  • Product Net Height : 130 mm

  • Product Net Depth / Length : 82.5 mm

  • Product Net Weight : 1.2 kg

  • Number of Poles : 3

  • Rated Operational Voltage : 690 V AC , 500 V DC

  • Product Main Type : SACE Tmax XT

  • Product Name : Moulded Case Circuit Breaker

  • Rated Frequency (f) : 50 / 60 Hz

  • Product Type : CB

  • Version : F

  • Electrical Durability : 120 cycles per hour , 8000 cycle

  • Mechanical Durability : Nr. Operations 240 cycles per hour, Nr. Operations 25000 cycle

  • Terminal Connection Type : Fixed Circuit-Breakers Front

  • Standards : IEC

Product Specification

Rated current

Type

Product id

1.6 A

1SDA067584R1

XT2H 160 TMD 1,6-16 3p F F

2 A

1SDA067585R1

XT2H 160 TMD 2-20 3p F F

2.5 A

1SDA067586R1

XT2H 160 TMD 2,5-25 3p F F

3.2 A

1SDA067587R1

XT2H 160 TMD 3,2-32 3p F F

4 A

1SDA067588R1

XT2H 160 TMD 4-40 3p F F

5 A

1SDA067589R1

XT2H 160 TMD 5-50 3p F F

6.3 A

1SDA067590R1

XT2H 160 TMD 6,3-63 3p F F

8 A

1SDA067591R1

XT2H 160 TMD 8-80 3p F F

10 A

1SDA067592R1

XT2H 160 TMD 10-100 3p F F

12.5 A

1SDA067593R1

XT2H 160 TMD 12,5-125 3p F F

16 A

1SDA067594R1

XT2H 160 TMD 16-300 3p F F

20 A

1SDA067595R1

XT2H 160 TMD 20-300 3p F F

25 A

1SDA067596R1

XT2H 160 TMD 25-300 3p F F

32 A

1SDA067597R1

XT2H 160 TMD 32-320 3p F F

40 A

1SDA067598R1

XT2H 160 TMA 40-400 3p F F

50 A

1SDA067599R1

XT2H 160 TMA 50-500 3p F F

63 A

1SDA067600R1

XT2H 160 TMA 63-630 3p F F

80 A

1SDA067601R1

XT2H 160 TMA 80-800 3p F F

100 A

1SDA067602R1

XT2H 160 TMA 100-1000 3p F F

125 A

1SDA067603R1

XT2H 160 TMA 125-1250 3p F F

160 A

1SDA067604R1

XT2H 160 TMA 160-1600 3p F F
