Bosch CCS700 Conference Control Unit CCSE-CU
PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments
Product Description
-
Better discussion control
-
Controls up to 50 Discussion units
-
3-Band equaliser for better sound performanc
-
Audio interfaces for connecting external audio equipments
-
The CCS700 Ultro Discussion System is suitable for use in meetings and conference venues with a limited number of participants
-
The Control Unit (CU) is the heart of the CCS700 Ultro Discussion System and supplies the power for all delegate and chairman units in the system
-
The unit also controls the chairman and delegate unit microphones,as well as providing interfaces for external audio equipment
-
The CCS700 discussion system is a plug and play solution for the audio conference requirements
-
Functions
-
Discussion Control
-
The CCSE-CU(CU) supports almost any kind of small or medium meeting
-
For business discussions and small conferences,two to six microphones can be active simultaneously,with the chairman always having speaker priority
-
The active microphone selection knob on the rear panel can be used to select the number of active participants
-
Unused microphones are switched off automatically after 65 seconds if delegates forget to switch off their units
-
Supplies Power For Up To 50 Discussion Units
-
The CU has two trunk outputs for the loop through connection of discussion units
-
It is possible to connect a maximum of 25 discussion units to each trunk output in open loop configuration
-
Maximum trunk length supported by CU is 100m in open loop configuration
-
For closed loop configuration with 50 discussion units the loop length can be extended upto 200meter
-
A maximum of 50 discussion units can be connected to a CU
-
Better Sound
-
The conference controller has a 3-band equaliser for tuning sound output of the system
-
This helps in quickly tuning the system to compliment the hall acoustics at different venues
-
This ensures optimum performance at all times
-
Audio Interfaces
-
The CU can be interfaced with different type of devices like external audio recorder,sound reinforcement system,external microphones and external music player
-
The headphone output on the front of the CU can be used by a secretary for taking the minutes of the meeting,the headphone output also has a volume control knob to adjust the volume of the headphone
-
To support external participants (during town-council meetings,for example), extra microphones in any style (wired, wireless,handheld or podium) can be connected to the system through mic inputs
-
Controls And Indicators
-
Equaliser comprising of knobs at 250Hz,2kHz and 8kHz
-
Volume control for Mic 1 input
-
Volume control for Mic 2 / Aux input
-
Headphone input and volume control
-
Master volume control
-
Sliding switch for Equaliser On/Off
-
Sliding switch to enable or disable the priority tone for chairman units
-
Number of Active microphone control knob
-
Interconnections
-
Trunk input and output 8-pin DIN connectors for loop through connection
-
Microphone input with XLR connector
-
Configurable Mic or Aux input with 6.5mm phono jack
-
Cinch connectors for connecting to external PA system and recorder
-
Earth connection screw
-
Mains socket
Product Specification
|
Brand |
Bosch |
|
Product Type |
Conference Control |
|
Product Model |
CCSE-CU |
|
Electrical |
|
|
Mains Voltage |
230VAC,50 Hz (±10%) |
|
DC Voltage Supply To Contribution Units |
24V ± 1V DC |
|
THD At Rated Output |
<1% |
|
SNR |
>-50dB at rated output (unweighted filter) |
|
Inputs |
|
|
Mic Input Sensitivity |
1 mV (+1/-3dB) |
|
Aux Input Sensitivity |
100mV (+1/-3dB) |
|
Frequency Response |
200 Hz to 12 kHz |
|
Input Impedance |
4.7 kohm |
|
Equaliser |
|
|
Center Frequencies Of Filters |
250Hz,2kHz and 8kHz |
|
Filter Bandwidth |
1 octave |
|
Boost/Cut At Center Frequencies |
+6dB to -6dB |
|
Equaliser Transfer Gain |
±1dB |
|
PA Output |
|
|
Rated Output Impedance |
100 ohm |
|
SNR |
>-50dB at rated output (unweighted filter) |
|
REC Out |
|
|
Rated Output Impedance |
1 kohm |
|
SNR |
>-50dB at rated output (unweighted filter) |
|
Environmental |
|
|
Operating Temperature |
-5 ºC to +45 ºC |
|
Storage And Transport Temperature |
-40 ºC to +70 ºC |
|
Mechanical |
|
|
Color |
Charcoal(RAL 10736) and Grey (for rear cover) |
|
Dimensions (W x H x D) |
88 x 361 x 252 mm |
|
Weight |
5.5 kg |
|
Warranty |
As Per Manufacturer Terms and Condition |
Other Details
|
Dimension (MM) – W x H x D |
88 x 361 x 252 |
|
Unit of Measurement |
1 Piece |
|
Weight |
5.5 kg |
|
Generic Type |
Conference Control |
|
Manufacturer Details |
Bosch Limited Post Box No: 3000,Hosur Road, Adugodi, Bangalore - 560030, India, Phone :18004258665 |
|
Packer Details |
Bosch Limited Post Box No: 3000,Hosur Road, Adugodi, Bangalore - 560030, India, Phone :18004258665 |
|
Country of Origin |
India |
