SKU # 1000139400
Hikvision Turbo HD DVR 8 Channel DS-7108HGHI-M1/T
PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments
Product Description
-
Key Features
-
8-ch 1080p Lite Mini 1U H.265 DVR
-
Support all channels motion detection technology
-
H.265 Pro+/H.265 Pro/H.265 video compression
-
HDTVI/CVI/AHD/IP/CVBS video inputs
-
Audio over coaxial cable
-
Support all channels HDTVI two-way audio technology
-
Up to 10-ch IP camera inputs
Product Specification
|
Brand |
Hikvision |
|
Product Type |
DVR |
|
Product Model |
DS-7108HGHI-M1/T |
|
Motion Detection 2.0 |
|
|
Human/Vehicle Analysis |
Deep learning based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported; |
|
Video And Audio |
|
|
IP Video Input |
2-ch (up to 10-ch) Up to 5MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras |
|
Analog Video Input |
8-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
|
HDTVI Input |
1080p25, 1080p30, 720p25, 720p30 |
|
AHD Input |
1080p25, 1080p30, 720p25, 720p30 |
|
HDCVI Input |
1080p25, 1080p30, 720p25, 720p30 |
|
CVBS Input |
Support |
|
HDMI Output |
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
|
VGA Output |
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
|
Video Output Mode |
HDMI/VGA simultaneous output |
|
Audio Input |
1-ch RCA (2.0 Vp-p, 1 KΩ) 8-ch via coaxial cable |
|
Output |
1-ch, RCA (Linear, 1 KΩ) |
|
Two-Way Audio |
Reuse the first audio input |
|
Synchronous Playback |
8-ch |
|
Recording |
|
|
Video Compression |
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
|
Encoding Resolution |
For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF For 720p stream access: 720p/WD1/4CIF/VGA/CIF For SD stream access: WD1/4CIF/VGA/CIF |
|
Frame Rate |
Main stream: For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF@15 fps For 720p stream access: 720p/WD1/4CIF/VGA/CIF@15 fps For SD stream access: WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) Sub-stream: For 1080p and 720p stream access CIF/QVGA@15 fps For SD stream access: CIF/QVGA@25 fps (P)/30 fps (N) |
|
Video Bitrate |
32 Kbps to 4 Mbps |
|
Stream Type |
Video, Video & Audio |
|
Audio Compression |
G.711u |
|
Audio Bitrate |
64 Kbps |
|
Network |
|
|
Total Bandwidth |
72 Mbps |
|
Network Protocol |
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP,UPnP, HTTPS |
|
Remote Connection |
64 |
|
Network Interface |
1, RJ45 10/100 Mbps self-adaptive Ethernet interface |
|
Auxiliary Interface |
|
|
SATA |
1 SATA interface |
|
Capacity |
Up to 4 TB capacity for each disk |
|
USB Interface |
Rear panel: 2 × USB 2.0 |
|
Alarm In/Out |
N/A |
|
General |
|
|
Power Supply |
12 VDC, 1.5 A |
|
Consumption |
≤ 10 W (without HDD) |
|
Working Temperature |
-10 °C to 55 °C (14 °F to +131 °F) |
|
Working Humidity |
10% to 90% |
|
Dimension (W × D × H) |
200 × 200 × 48 mm (7.9 × 7.9 × 1.9 Inch) |
|
Weight |
≤ 1 kg (without HDD, 2.2 lb.) |
|
Warranty |
As Per Manufacturer Terms and Condition |
Other Details
|
Dimension (CM) L x B x H |
20 x 20 x 4.8 |
|
Unit Of Measurement |
1 Piece |
|
Weight |
1 kg |
|
Generic Name |
8 Channel DVR |
|
Manufacturer Details |
Prama Hikvision India Pvt. Ltd., Oberoi Commerz 2, International Business Park, 18th Floor, Near Oberoi Mall, Off W. E. Highway, Goregaon (East), Mumbai-400 063. Phone : +91-22-4041 9900 |
|
Packer Details |
Prama Hikvision India Pvt. Ltd., Oberoi Commerz 2, International Business Park, 18th Floor, Near Oberoi Mall, Off W. E. Highway, Goregaon (East), Mumbai-400 063. Phone : +91-22-4041 9900 |
|
Country Of Origin |
India |
