SKU # 1000077496
Hikvision 4MP IPC Bullet Camera 50m H.265+ DS-2CD1T43G0-I
PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments
Product Description
-
4 MP Fixed Bullet Network Camera
-
High quality imaging with 4 MP resolution
-
Clear imaging against strong back light due to 120 dB WDR technology
-
Efficient H.265+ compression technology
-
Water and dustresistant (IP67)
-
Easy installation with Power over Ethernet (PoE) technology
-
3D DNR technology delivers clean and sharp images
ProductSpecification
Brand |
Hikvision |
Product Type |
Bullet Camera |
Product Code |
DS-2CD1T43G0-I |
Camera | |
Image Sensor |
1/3″ Progressive Scan CMOS |
Min. Illumination |
Color: 0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR |
Shutter Time |
1/3 s to 1/100, 000 s |
Slow Shutter |
Yes |
Wide Dynamic Range |
120dB |
Day & Night |
IR cut filter |
Linkage Method |
Upload to FTP, notify surveillance center, send email, trigger capture |
Angle Adjustment |
Pan: 0° to 360°, tilt: 0° to 180°, rotate: 0° to 360° |
Lens | |
Focal Length & FOV |
4 mm, horizontal FOV 75°, vertical FOV 41°, diagonal FOV 88°; 6 mm, horizontal FOV 49°, vertical FOV 26°, diagonal FOV 57° |
Aperture |
4 mm F2.0; 6mm F1.6 |
Lens Mount |
M12 |
Illuminator | |
IR Range |
50 m |
Wavelength |
850nm |
Smart Supplement Light |
Yes |
Video | |
Max. Resolution |
2560 × 1440 |
Main Stream |
50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720); 60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720) |
Sub Stream |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240); 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
Video Compression |
Main Stream: H.265/H.264/H.264+/H.265+; sub-stream: H.265/H.264 /MJPEG |
Video Bit Rate |
32 Kbps to 8 Mbps |
H.264 Type |
Baseline Profile/Main Profile/High Profile |
H.265 Type |
Main Profile |
Region of Interest (ROI) |
1 fixed region for main stream and sub-stream |
Network | |
Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
Simultaneous Live View |
Up to 6 channels |
API |
ONVIF (PROFILE S, PROFILE G), ISAPI, SDK |
Smooth Streaming |
Yes |
User/Host |
Up to 32 users. 3 levels: administrator, operator and user |
Security |
Password protection, complicated password, HTTPS encryption, watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2 |
Network Storage |
NAS (NFS, SMB/CIFS) |
Client |
iVMS-4200, Hik-Connect, Hik-Central |
Web Browser |
IE8+, Chrome31.0-44, Firefox30.0-51, Safari8.0+ |
Image | |
Image Settings |
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
Smart IR |
Yes |
Day/Night Switch |
Day, Night, Auto, Schedule |
SNR |
≥ 52 dB |
Image Enhancement |
BLC, HLC, 3D DNR |
Interface | |
Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
Event | |
Basic Event |
Motion detection, video tampering alarm |
General | |
Firmware Version |
V5.5.84 |
Web Client Language |
English, Russian, Italian, French, Polish, Spanish, Turkish, Portuguese |
General Function |
Anti-flicker, heartbeat, mirror, password protection, privacy masks, watermark, IP address filter |
Software Reset |
Yes |
Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
Power Supply |
12 VDC ± 25%, PoE: 802.3af, Type 1 Class 3, reverse polarity protection |
Power Consumption and Current |
12 VDC, 0.50 A, max. 6W; PoE (802.3af, 36 V to 57 V), 0.20 A to 0.10 A, max. 7 W |
Power Interface |
Φ5.5 mm coaxial power plug |
Material |
Front cover & bracket: metal; back cover & sun shield: plastic |
Approval | |
Protection |
Ingress protection: IP67 (IEC 60529-2013) |
EMC |
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); IC (ICES-003: Issue 6, 2016) |
Safety |
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015) |
Environment |
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
Camera Dimension |
71.67 × 92.87 × 221.49 mm (2.82" × 3.65" × 8.72") |
Package Dimension |
234 × 120 × 117 mm (9.21″ × 4.72″ × 4.61″) |
Camera Weight |
500 g (1.10 lb.) |
With Package Weight |
670 g (1.48 lb.) |
Warranty |
As Per Manufacturer Terms and Condition |
Other Details
Dimension (CM) - L x B x H |
|
Unit of Measurement |
|
Weight |
kg |
Generic Type |
Bullet Camera |
Manufacturer Details |
Prama Hikvision India Pvt. Ltd., Oberoi Commerz 2, International Business Park, 18th Floor, Near Oberoi Mall, Off W. E. Highway, Goregaon (East), Mumbai-400 063. Phone : +91-22-4041 9900 |
Packer Details |
Prama Hikvision India Pvt. Ltd., Oberoi Commerz 2, International Business Park, 18th Floor, Near Oberoi Mall, Off W. E. Highway, Goregaon (East), Mumbai-400 063. Phone : +91-22-4041 9900 |
Country of Origin |
India |
