SKU # 1000012168
ABB MCCB Power Distribution SACE Tmax XT 16-160A 16KA 415 VAC Four Pole – XT1B 160 TMD 4p
PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments
Product Description
-
C.Breaker Tmax XT1B 160 Fixed Four-Pole With Front Terminals And Thermomagnetic Release TMD
-
Product Net Width :101.6 mm
-
Product Net Height : 130 mm
-
Product Net Depth / Length : 70 mm
-
Product Net Weight :1.4 kg
-
Number of Poles : 4
-
Power Loss : at Rated Operating Conditions per Pole 1.5 W
-
Circuit Breaker Type to be Associated: Power distribution
-
Product Main Type : SACE Tmax XT
-
Product Name : Moulded Case Circuit Breaker
-
Product Type : Air Circuit Breaker
-
Rated Frequency (f):50 / 60 Hz
-
Rated Operational Voltage : 690 V AC,500 V DC
-
Electrical Durability:120 cycles per hour, 8000 cycle
-
Mechanical Durability:Nr. Operations 240 cycles per hour,Nr.Operations 25000 cycle
-
Version:F
-
Terminal Connection Type:Fixed Circuit-Breakers Front
-
Standards:IEC
Product Specification
|
Rated current |
Type |
Product id |
|
16 A |
1SDA066810R1 |
XT1B 160 TMD 16-450 4p F F |
|
32A |
1SDA066813R1 |
XT1B 160 TMD 32-450 4p F F |
|
40 A |
1SDA066814R1 |
XT1B 160 TMD 40-450 4p F F |
|
63 A |
1SDA066816R1 |
XT1B 160 TMD 63-630 4p F F |
|
80 A |
1SDA066817R1 |
XT1B 160 TMD 80-800 4p F F |
|
100 A |
1SDA066818R1 |
XT1B 160 TMD 100-1000 4p F F |
|
125 A |
1SDA066888R1 |
XT1B 160 TMD 125-1250 4p F F InN=100% |
|
160 A |
1SDA066821R1 |
XT1B 160 TMD 160-1600 4p F F InN=100% |
Other Details
Dimension (CM) - L x B x H |
|
Unit of Measurement |
|
Weight |
kg |
Generic Type |
4 Pole MCCB |
Manufacturer Details |
ABB India Limited, 88/3-88/6 Basavanahalli Village, Kasaba Hobli, Bangalore North, 562123- Bangalore-Karnataka, Phone: +91-8448233444 |
Packer Details |
ABB India Limited, 88/3-88/6 Basavanahalli Village, Kasaba Hobli, Bangalore North, 562123- Bangalore-Karnataka, Phone: +91-8448233444 |
Country of Origin |
India |
