48 hours

SKU # 1000129216


CP Plus 4 Channel Digital Video Recorder 1080N CP-UVR-0401E1-IC

CP Plus 4 Channel Digital Video Recorder 1080N CP-UVR-0401E1-IC


₹ 3,010.00

Quantity

Pack Qty : 1



Delivery Availability

 Estimated Dispatch Within 2 Days

EMI Available.

On minimum purchase of ₹ 3000/-

PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments

Product Description

  • Supports HDCVI/AHD/TVI/CVBS/IP video inputs

  • Maximum 5 channels IP camera inputs, each channel up to 2MP; Maximum 20Mbps Incoming Bandwidth

  • Supports Full-channel AI-Coding

  • Instastream/H.265 dual-stream video compression

  • Up to 4 channels video stream (analog channel) SMD Plus

  • Support 1 SATA HDD up to 6TB, 2 USB Ports

  • 1 HDMI / 1 VGA Simultaneous Video Output

  • Mobile Software: iCMOB, gCMOB

  • CMS Software: KVMS Pro

  • System Overview

  • CP Plus has introduced the new and impactful range of DVRs under the Lite Series which has been
    integrated with the 4K and H.265 encoding technolo- gy that provides you with an outstanding at a
    reasonably pocket-friendly price

  • The 4K resolution processors present in this product help in bringing out every little detail in the image

  • Along with that, this DVR uses the intuitive shortcut operation menu which lets you control and manage the system remotely as well and can work as edge storage, central storage, backup storage

  • Signal Auto-Adapt

  • This DVR recognizes the signal type (CVI, TVI, AHD, CVBI) and automatically adapts without requiring any manual interven- tion

  • This has provided much ease to the user since signal compatibility was always a towering concern

  • Additonal IP Cameras Support

  • In some installations, customers have specific features and functions that are available in IP cameras only, such as two-way communication, edge storage, alarm I/O, etc

  • CP PLUS DVRs provide additional IP camera support to provide flexibility so that the desired solution features can be made accessible

  • Secured Password Policy (SPP)

  • Amid rising security challenges such as hacking, phishing, etc

  • CP PLUS has framed strict policies to increase the security of surveillance systems, in which it makes it mandatory to change the default password to one that is alphanumeric

  • Multi-Signal Support

  • CP PLUS DVRs are equipped with UNI+ technology which supports all HD and analog video formats

  • This helps the user upgrade their systems without requiring major overhauls

  • gCMOB/ iCMOB

  • Designed to allow users to access and control live streaming from CP PLUS IP Cameras, DVRs/ NVRs and Video Door Phones, the CP PLUS gCMOB/ iCMOB application offers a host of features such as Easy GUI, up to 16 live viewing split-ups; InstaOn cloud support; Playback; digital zoom ins; two-way talk, and more

  • KVMS Pro

  • The KVMS Pro is a hybrid security management software that allows the management of various surveillance devices such as cameras, DVRs/ NVRs, encoders/ decoders, etc

  • It is re-leased with the surveillance hardware and exclusively sup-ports CP PLUS devices

Product Specification

Brand

CP Plus

Product Type

DVR

Product Model

CP-UVR-0401E1-IC

Processor

Embedded processor

Operating System

Embedded LINUX

IP Camera Input

4+1 channels, each channel up to 2MP

Two-Way Talk

Reuse audio in/out, RCA

User Interface

GUI

Performance SMD Plus

4 Channels

AI Search SMD

Search by target classification (Human, Vehicle)

Video Input

4 channel, BNC

Video Output

1 HDMI, 1 VGA

Video Compression

AI Instastream/Instastream/H.265/H.264+/H.264

Video Resolution

1920×1080, 1280×1024, 1280×720

Resolution

1080N; 720P; 960H; D1; CIF

Video Recording

Main Stream: All channels 1080N/720P/960H/D1/CIF/(1~25/30fps) Sub stream: CIF (1~15 fps)

Video Display Split

1/4

OSD

Camera title, Time, Video loss, Camera lock, Motion detection, Recording

Bit Rate

32 kbps–4096 kbps per channel

Audio Input

1 channel, RCA

Audio Output

1 channel, RCA

Audio Sample Rate

8KHz, 16 bit Per Channel

Audio Bit Rate

64Kbps Per Channel

Motion Detection

Support

Video Loss

Support

Audio Compression Camera Blank

G.711A, G.711U, PCM Support

Smart Phone

iPhone, iPad, Android Phone

Hard Disk

1 SATA port, up to 6TB Each

Trigger Events

Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips

Playback

1/4 Ch

Recording Mode

Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss,
Tampering), Alarm, Stop

Search Mode

Time/Date, Alarm, MD & Exact search (accurate to second)

Playback Function

Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous
camera, Full screen, Repeat, Shuffle, Backup, selection, Digital zoom

Backup Mode

USB Device/Network

Interface Ports

2 USB Ports (USB 2.0)

Maximum User Access

128 users

Record Interval

1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec

Ethernet

1 RJ-45 port (100Mbps)

Protocols

HTTP; HTTPS; TCP/IP; IPv4/IPv6; 3G/4G; UPnP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter;
PPPoE; DDNS; FTP; Alarm Server; InstaOn; IP Search, ONVIF 16.12, CGI Conformant

Power Supply

DC12V/1.5A

Power Consumption

<7W (without HDD)

Working Temperature

10°C ~ +45°C (+14°F ~ +113°F), 0 ~ 90% (RH)

Dimension

198 × 203.0 × 41.5 mm

Weight

0.57kg (without HDD)

Warranty

As Per Manufacturer Terms and Condition

Other Details

Dimension (CM) - L x B x H

9.7 x 9.5 x 6

Unit Of Measurement

1 Piece

Weight

0.319 kg

Generic Type

4 Channel DVR

Manufacturer Details

Aditya Infotech Ltd.(CP PLUS) A-12, Sector 4, NOIDA - 201301 (Delhi-NCR) India Phone : 18001026526

Packer Details

Aditya Infotech Ltd.(CP PLUS) A-12, Sector 4, NOIDA - 201301 (Delhi-NCR) India Phone : 18001026526

Country Of Origin

India
