SKU # 1000139793
CP Plus 4MP Built-In-Mic Network IR Bullet Camera CP-UNC-TA41L6C-D-Q-0600
PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments
Product Description
-
Key Features
-
1/2.8" 4MP PS CMOS Image Sensor (0.9071 centimeters)
-
Maximum 4MP (2688 × 1520)/ (2560 × 1440)@1-25/30fps
-
Instastream, H.265, H.264, H.264H, H.264B, MJPEG
-
Support Triple stream
-
Support Built-in Mic, Built-in speaker
-
3.6mm fixed Lens
-
WDR (120dB), Day/Night (ICR), 3D NR, ROI, AWB, AGC, BLC, HLC, Digital watermarking
-
IR Range of 30 Mtr., Warm Light Range of 30 Mtr., PoE, IP67
-
When the scene is too dark, the image is captured by illuminating an infrared light through the camera onto the scene that greatly helps with making the scene visible for the lens
-
It delivers color images during the day and automatically switches to the monochrome feature as the scene darkens
-
Regions of Interest (ROI) is a user defined feature that allows the operator to monitor specific areas of a scene while still maintaining overall situational awareness of less important areas
-
This camera has been designed with the latest and most efficient innovation among the standard video compression designs
-
Smart encoding algorithms developed by CP PLUS help in saving up to 70% more bandwidth than H.265 along with making it more beneficial for minimizing bandwidth and storage costs
-
It enhances video coding efficiency while providing high resolution and the rate of frame in the video using Intelligent Region Perception to detect motion in each frame
-
CP PLUS cameras with Power over Ethernet (PoE) technology offer a simple and efficient installation by using a single Ethernet cable to deliver both power and data
-
This eliminates the need for separate power adapters, reduces cable clutter, and ensures a cleaner setup
Product Specification
|
Brand |
CP Plus |
|
Product Type |
CCTV Camera |
|
Product Model |
CP-UNC-DA41L3B-D-LQ |
|
Image Sensor |
1/2.8" 4MP PS CMOS Image Sensor (0.9071 centimeters) |
|
Minimum Illumination |
0.001 lux@F1.4 (Color, 30 IRE), 0.0001 lux@F1.4 (B/W, 30 IRE), 0 lux (IR on) |
|
Effective Pixels |
2688 (H) × 1520 (V) |
|
Angle Adjustment |
Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360° |
|
Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
|
White Balance |
Auto, Natural, Street lamp, Outdoor, Manual, Regional custom |
|
RAM |
128 MB |
|
ROM |
128 MB |
|
Close Focus Distance |
3.2 m |
|
Gain Control(AGC) |
Auto, Manual |
|
Lens Type |
Fixed-focal |
|
Maximum Aperture |
F1.4 |
|
Lens Mount |
M12 |
|
DORI Distance |
124.0 m (Detect), 49.6 m (Observe), 24.8 m (Recognize), 12.4 m (Identify) |
|
Video Format |
PAL/NTSC |
|
OSD |
Camera title, Date & Time |
|
Lens |
6mm Fixed Lens |
|
Angle of view |
H: 49°, V: 26°, D: 57° |
|
S/N Ratio |
>58dB |
|
Video Compression |
Instastream, H.265, H.264, H.264H, H.264B, MJPEG (only supported by the sub stream) |
|
Back Light Compensation |
BLC/ HLC/ WDR (120dB) |
|
Day/Night |
Auto(ICR)/Color/B/W |
|
IR Number |
4 IR LED |
|
IR |
IR Range of 60 Mtr. |
|
Smart IR |
Support |
|
Resolution |
4MP (2688 x 1520)/ (2560 × 1440), 3MP (2304 × 1296), 2MP (1920 × 1080), 1.3MP (1280 × 960), 720p (1280 × 720), D1 (704 × 576/704 × 480), VGA (640 × 480), CIF (352 × 288/352 × 240) |
|
stream Capability |
Triple stream |
|
Frame Rate |
Main stream: 4MP (2688 × 1520)@1-25/30fps, 4MP (2560 × 1440)@1-25/30 Sub stream 1: 720P( 1280 × 720) D1 (704 × 576)@1–25 fps/ (704 × 480)@1–30 fps, VGA(640 × 480)@1-30fps, CIF (352 × 240)@1-30fps, (352 × 288) @1-25fps Sub stream 2: D1 (704 × 576)@1–25 fps/ (704 × 480)@1–30 fps, VGA(640 × 480)@1-30fps, CIF (352 × 240)@1-30fps/ (352 × 288) @1-25fps |
|
Motion Detection |
OFF/ON (4 areas, rectangular) |
|
Privacy Mask |
4 areas |
|
ROI |
Support (4 Areas) |
|
Audio Compression |
G.711a, G.711Mu, PCM, G.726, AAC |
|
Mirror Function |
Support |
|
Audio |
Built-In Mic |
|
Bit Rate |
H.265: 3 kbps-6144 kbps, H.264: 8 kbps-6144 kbps |
|
Bit Rate Control |
CBR/VBR |
|
Human body Detection |
Support the classification and accurate detection of human |
|
Protocol |
SFTP, IPv6, IPv4, DNS,RTCP, NTP, RTP, HTTP, HTTPS, SNMP V3, TLS Version 1.2, TCP/IP, PPPoE, NFS, UDP, ICMP, IGMP, SSL, DHCP, SMTP, RTSPS, ONVIF (Profile S, Profile G, Profile T), unicast, multicast |
|
Noise Reduction |
3D NR |
|
Ethernet |
RJ-45 (10/100 Base-T) |
|
SDK and API |
Support |
|
Alarm Event |
Network disconnection, IP conflict, illegal access, Motion detection, Video tampering, Audio detection, IMD (Intelligent motion detection), Security exception |
|
Cyber Security |
AES 256-bit Encryption, Configuration encryption, trusted execution, Digest, security logs, WSSE, account lockout, syslog, video encryption, IP/MAC filtering, HTTPS, trusted upgrade, trusted boot |
|
Browser |
IE, Chrome, Firefox |
|
IR Control |
Auto, Manual |
|
Image Rotation |
4MP only support 0°/180° 1080P & lower will support 0°/90°180°/270° |
|
Smart search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
|
Iris Control |
Fixed |
|
User/Host |
6 (Total bandwidth: 36 M) |
|
Weatherproof Standard |
IP67 |
|
Certificates |
ISO 9001: 2015, ISO 20000-1 : 2018, CE, FCC and RoHS, BIS, STQC approved compliance report |
|
Power Source |
12 VDC/PoE (802.3af) |
|
Power Consumption |
Basic: 2 W (12 VDC); 2.9 W (PoE) Maximum (H.265 + intelligence on+ WDR + illuminator intensity): 5.3W (12 VDC), 6.8 W (PoE) |
|
Operating Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
|
Operating Humidity |
≤95% |
|
Storage Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
|
Storage Humidity |
≤95% |
|
Casing |
Metal + Plastic |
|
Dimension |
197.9 mm × 80.2 mm × 76.2 mm |
|
Weight |
310 g |
|
Warranty |
As Per Manufacturer Terms and Condition |
Other Details
|
Dimension (CM) L x B x H |
19.79 x 8.02 x 7.62 |
|
Unit Of Measurement |
1 Piece |
|
Weight |
0.31 kg |
|
Generic Name |
Bullet Camera |
|
Manufacturer Details |
Aditya Infotech Ltd.(CP PLUS) A-12, Sector 4, NOIDA - 201301 (Delhi-NCR) India Phone : 18001026526 |
|
Packer Details |
Aditya Infotech Ltd.(CP PLUS) A-12, Sector 4, NOIDA - 201301 (Delhi-NCR) India Phone : 18001026526 |
|
Country Of Origin |
India |
