SKU # 1000022908

ABB AC Type Contactor Three Ploe UA63-30-00RA

ABB AC Type Contactor Three Pole UA63-30-00RA


₹ 8,725.00

Quantity

Min Qty : 1



Delivery Availability
EMI Available.

On minimum purchase of ₹ 3000/-

PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments

Product Description

  • UA63..RA 3-pole contactors for capacitor switching, can be used in installations in which the peak current far exceeds 100 times nominal rms current

  • The contactors are delivered complete with their damping resistors and must be used without additional inductances (see table below)

  • The capacitors must be discharged (maximum residual voltage at terminals ≤ 50 V) before being re-energized when the contactors are making

  • Number of Main Contacts NO : 3

  • Number of Main Contacts NC : 0

  • Number of Auxiliary Contacts NO : 0

  • Number of Auxiliary Contacts NC : 0

  • Rated Operational Voltage : Main Circuit 690 V

  • Short-Circuit Protective Devices : gG Type Fuses 200 A

  • Maximum Electrical Switching Frequency : 240 cycles per hour

  • Rated Impulse Withstand Voltage (Uimp) : 8 kV

  • Terminal Type : Screw Terminals

  • Product Net Width : 70 mm

  • Product Net Depth / Length : 140.4 mm

  • Product Net Height : 150 mm

  • Product Net Weight : 1.35 kg

Product Specification

Rated Voltage

Type

Product Id

24V

UA63-30-00RA

1SBL371024R8100

110V 50Hz / 110-120V 60Hz

UA63-30-00RA

1SBL371024R8400

220-230V 50Hz / 230-240V 60Hz

UA63-30-00RA

1SBL371024R8000

400-415V 50Hz / 415-440V 60Hz

UA63-30-00RA

1SBL371024R8600
