Havells HGS 12 Power Magnetic Contactors With AC Coil 3 Pole 1NO Frame1

Havells HGS 12 Power Magnetic Contactors With AC Coil 3 Pole 1NO Frame1

Visit the Havells Store

₹ 6,760.00

Quantity

Pack Qty : 1



Delivery Availability

Offers and Coupons

Dussehra Sale

Coupon Image

Use the coupon codes purchase of ₹7,000/- & above

Above ₹7,000
Use
GND100
Above ₹14,000
Use
GND200
Above ₹21,000
Use
GND300
Coupon Image

Register to use Coupon Code C50 and get ₹50/- off on a purchase of ₹1000/- & above

EMI Icon

EMI Available On minimum purchase of ₹ 3000/-

PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments

Product Description

  • Cassette Type Design and universal Coil

  • Completely Shield for dusty atmosphere

  • Nut Retaining Washer for quick termination

  • DIN rail mounting up to 100 A

  • Snap fit construction up to 40 A

  • Class H Insulation

  • Operating Band

  • Wide band coil to withstand high fluctuation

  • Design

  • Snap fit design & completely shield for dusty atmosphere

  • Snap Open Design for Easy Inspection

  • Low VA burden coils and is considered to be the greenest contactors

  • Nut Retaining Washer for Quick Termination

  • High electrical & mechanical life

  • High Endurance / Switching Frequency

  • Conforms to IS / IEC 60947-4-1

  • *Actual product image may vary from that shown on the picture

Product Specification

Brand

Havells

Product Type

Contactors

Product Code | Coil Voltage

IHPHA012110B | 24V AC

IHPHA012110H | 110V AC

IHPHA012110N | 240V AC

IHPHA012110S | 150-300V AC

IHPHA012110W | 260-440V AC

IHPHA012110T | 415V AC

Type

HGS 12

Frame Size

1

AC-3 Duty Rating At 415 V,50 Hz

Ie A

12 A

kW

5.5 kW

HP

7.5 HP

AC-1 Duty Rating At 415 V,50 Hz

Ith A

30 A

Power Poles

3

Auxilliary Contact Arrangement

NO

1

NC

0

IP Protection

20°

Warranty

As Per Manufacturer Terms and Condition

Other Details

Dimension (CM) - L x B x H

Unit of Measurement

Weight

kg

Generic Type

3 Pole Contactors

Manufacturer Details

Havells India Ltd. Office: QRG Towers, 2D, Sector-126, Expressway, Noida-201304 (U.P), Phone : +91-120-3331000 Email: marketing@havells.com

Packer Details

Havells India Ltd. Office: QRG Towers, 2D, Sector-126, Expressway, Noida-201304 (U.P), Phone : +91-120-3331000 Email: marketing@havells.com

Country of Origin

India
