Available

SKU # 1000021798

ABB-AC-Type-Mini-Contactor-Three-Pole-VB7-30-10-1000021798

ABB AC Type Mini Contactor Three Pole VB7-30-10


₹ 2,523.00

Quantity

Min Qty : 1



Delivery Availability
EMI Available.

On minimum purchase of ₹ 3000/-

PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments

Product Description

  • The VB7-30-10 mini reversing contactor is a compact 3 pole contactor with 1 auxiliary contact, screw terminals and normal mechanical interlock

  • They are ideally suited for applications where reliability is a must and space is at a premium

  • Mini reversing contactors are used in residential buldings, commercial buildings and industrial applications for the control of three-phase motor loads up to 4 kW (AC-3)

  • Further features are the silent coil, a switch position indication and the integrated possibility for rail or wall mounting

  • Number of Poles : 4

  • Rated Impulse Withstand Voltage (Uimp) : Main Circuit 6 kV

  • Rated Insulation Voltage (Ui) : 690 V , acc. to UL/CSA 600 V

  • Number of Main Contacts NC : 0

  • Number of Main Contacts NO : 3

  • Number of Auxiliary Contacts NC : 0

  • Number of Auxiliary Contacts NO : 1

  • Conventional Free-air Thermal Current (Ith) : Main Circuit 20 A

  • Pollution Degree : 3

  • Mechanical Durability : 10000000 cycle

  • Product Net Width : 96.5 mm

  • Product Net Height : 57.5 mm

  • Product Net Depth / Length : 46.5 mm

  • Product Net Weight : 0.355 kg

Product Specification

Type

Product ID

Rated Control Circuit Voltage (Uc)

VB7-30-10-01 Mini Rev.Contactor

GJL1311901R0101

24 V AC

VB7-30-10-03 Mini Rev.Contactor

GJL1311901R0103

48 V AC

VB7-30-10-84 Mini Rev.Contactor

GJL1311901R8104

110 ... 127 V AC

VB7-30-10-80 Mini Rev.Contactor

GJL1311901R8100

220 ... 240 V AC

VB7-30-10-85 Mini Rev.Contactor

GJL1311901R8105

380 ... 415 V AC
