SKU # 1000104465
Havells HGS 185 Power Magnetic Contactors With DC Coil 3 Pole Frame6
PAN INDIA DELIVERY
100% Genuine Products
100% Secured Payments
Product Description
-
Cassette Type Design and universal Coil
-
Completely Shield for dusty atmosphere
-
Nut Retaining Washer for quick termination
-
DIN rail mounting up to 100 A
-
Snap fit construction up to 40 A
-
Class H Insulation
-
Operating Band
-
Wide band coil to withstand high fluctuation
-
Design
-
Snap fit design & completely shield for dusty atmosphere
-
Snap Open Design for Easy Inspection
-
Low VA burden coils and is considered to be the greenest contactors
-
Nut Retaining Washer for Quick Termination
-
High electrical & mechanical life
-
High Endurance / Switching Frequency
-
Conforms to IS / IEC 60947-4-1
-
*Actual product image may vary from that shown on the picture
Product Specification
|
Brand |
Havells |
|
Product Type |
Contactors |
|
Product Code | Coil Voltage |
IHPHA185600B | 24V DC IHPHA185600N | 110-220V DC IHPHA185600N | 240V DC IHPHA185600T | 415V DC |
|
Type |
HGS 185 |
|
Frame Size |
6 |
|
AC-3 Duty Rating At 415 V,50 Hz |
|
|
Ie A |
185 A |
|
kW |
100 kW |
|
HP |
135 HP |
|
AC-1 Duty Rating At 415 V,50 Hz |
|
|
Ith A |
275 A |
|
Power Poles |
3 |
|
Auxilliary Contact Arrangement |
|
|
NO |
2 |
|
NC |
2 |
|
IP Protection |
20° |
|
Warranty |
As Per Manufacturer Terms and Condition |
Other Details
Dimension (CM) - L x B x H |
|
Unit of Measurement |
|
Weight |
kg |
Generic Type |
3 Pole Contactors |
Manufacturer Details |
Havells India Ltd. Office: QRG Towers, 2D, Sector-126, Expressway, Noida-201304 (U.P), Phone : +91-120-3331000 Email: marketing@havells.com |
Packer Details |
Havells India Ltd. Office: QRG Towers, 2D, Sector-126, Expressway, Noida-201304 (U.P), Phone : +91-120-3331000 Email: marketing@havells.com |
Country of Origin |
India |
